The X20-7.4-M-835 Servos features a brushless motor, a full CNC aluminum case, and a complete set of hardened steel gears throughout each servo. The servo boasts an incredible 40Kgf.cm of torque at 7.4V and a crisp 0.13 second speed.
Features
- Hardened Steel Gears
- Extreme Torque and Excellent Speed
- Contactless Sensor
- 6 Ball Bearings
- Brushless DC Motor
- CNC Aluminium Case
Specification
- Item: X20-7.4-M-835 Servo
- Rated Voltage: DC7.4V
- Operating Voltage: DC6.0V-8.4V
-
Stalling Torque: 40Kgf.cm@7.4V
- Rated Torque: 10Kgf.cm@7.4V
- Stalling Current: 4.95A
- Rated Current: 1.25A
- No-load Speed: 0.13sec/60°@7.4V
- Rated Speed: 0.24sec/60°@7.4V
- Working Frequency: 1520μs/333Hz
- Default Travel Angle: ± 100°=200°Total, When 500μs-2500μs
- Temperature Range: -10℃……+65℃
- Case Material: Aluminum Alloy
-
Motor Type: Brushless DC Motor
- Gear Set Material: Hardened Steel
- Position Sensor: Contactless
- Ball Bearing: 6BB
- Weight: 80g±10%
- Case Dimensions: 40mm*20mm*40mm±0.2mm
