The new KST DS589MG is a high-voltage servo suitable for helicopter cyclic and all fixed-wing applications. At 15mm thick and 40g weight, it is reasonably small and light, considering its excellent 9.2 Kgf.cm of torque and 0.08 sec/60° speed. A similar size and torque as the well regared MKS HV737 and is faster and better value.
This servo uses a contactless sensor for position feedback. Also, see the KST MS589 servo which is the same size but uses a magnetic position sensor.
Features
- Hardened Steel Gears
- Extreme Torque and Excellent Speed
- CNC Aluminium Case
- Two Ball Bearings
- Programmable
- Ideal for RC Helicopter and Fixed Wing
Specification
- Item: DS589MG V8.0 Mini Servo
- Rated Voltage: DC7.4V
- Voltage Range: DC6.0V-8.4V
- Stalling Torque: 6.5Kgf.cm@6.0V, 8.0Kgf.cm@7.4V, 9.2Kgf.cm@8.4V
- No-load Speed: 0.10sec/60°@6.0V, 0.09sec/60°@7.4V, 0.08sec/60°@8.4V
- Working Frequency: 1520μs/333Hz
- Default Travel Angle: ±60°=120° Total
- Temperature Range: -20℃……+65℃
- Soft Start: Programmable
- Programmable: Yes
- Case Material: Aluminum Alloy
- Motor Type: Coreless DC Motor
- Gear Set Material: Hardened Steel
- Position Sensor: Potentiometer
- Case Dimensions: 35.5mm*15mm*32.5mm±0.2mm
- Weight: 40g±10%
