The CM633 is a high-performance, ultra-lightweight coreless servo, ideal for small-scale RC cars and aerobatic planes. It boasts a powerful 15.0 Kgf.cm of torque and a rapid response time of 0.08sec/60°. With its programmable capabilities, the CM633 offers easy adjustment and fine-tuning to meet your specific needs.
Features
- High Torque & Excellent Speed
- Light Weight and Compact Design
- Programmable
- Dual Ball Bearings
- Coreless DC Motor
- Ideal for Small Scale RC Cars & RC Aerobatics Planes
Specification
- Item: CM633 Servo
- Rated Voltage: DC7.4V
- Voltage Range: DC4.8V-8.4V
- Torque: 9.0Kgf.cm@4.8V / 12.0Kgf.cm@6.0V / 13.8Kgf.cm@7.4V / 15.0Kgf.cm@8.4V
- Speed: 0.14sec/60°@4.8V / 0.11sec/60°@6.0V / 0.09sec/60°@7.4V / 0.08sec/60°@8.4V
- Stalling Current: 1.85A@4.8V / 2.65A@6.0V / 2.95A@7.4V / 3.25A@8.4V
- Working Frequency: 1520μs/333Hz
- Default Travel Angle: ±50° =100° Total
- Temperature Range: -10℃.......+65℃
- Soft Start: Programmable
- Programmable: Yes
- Case Material: Aluminium Alloy
- Motor Type: Coreless DC Motor
- Gear Set Material: Metal Gear
- Position Sensor: Potentiometer
- Ball Bearing: 2BB
- Case Dimensions: 33mm*15mm*30mm±0.2mm
- Weight: 35g±10%
