KST DS725MG HV Digital Coreless Servo 18Kgf.cm 0.07sec for 550 & 700 Size RC Helicopter
Usually ships within 24 hours
Regular price
$71.50
Couldn't load pickup availability
KST DS725MG high voltage coreless servo is an amazing workhorse! Capable of running on 8.4 volts with ultra-high 18Kgf.cm torque and lightning speed of 0.07sec. This servo is ready to perform!
It is blistering fast even when run on 6 volts. A great servo for 550 & 700 sized heli's or other applications where high speed, precision, and huge strength are needed. Precision aerobatics, car steering, etc.
Features
- Extreme Torque and Excellent Speed
- CNC Aluminium Case
- Two Ball Bearings
- Programmable
- Ideal for for 550 & 700 Size RC Helicopter
Specification
- Item: DS725MG HV Servo
- Rated Voltage: DC7.4V
- Voltage Range: DC6.0V-8.4V
- Stalling Torque:
13Kgf.cm@6.0V
16Kgf.cm@7.4V
18Kgf.cm@8.4V
- No-load Speed:
0.09sec/60°@6.0V
0.08sec/60°@7.4V
0.07sec/60°@8.4V
- Working Frequency: 1520μs/333Hz
- Default Travel Angle: ±50°=100° Total
- Temperature Range: -10℃……+65℃
- Soft Start: Programmable
- Programmable: Yes
- Case Material: Aluminum Alloy
- Motor Type: Coreless DC Motor
- Gear Set Material: Hardened Steel
- Position Sensor: Potentiometer
- Ball Bearing: 2BB
- Case Dimensions: 40.5mm*20mm*38mm±0.2mm
- Weight: 70g±10%
