Characteristics
· 80x hybrid zoom camera with 4K resolution, powered by the AI-ISP full-color night vision imaging engine, delivers clear full-color images in low-light environments. Featuring advanced HDR capability, it ensures both highlights and shadow details remain vividly visible even in complex lighting scenarios with extreme brightness contrasts.
· Features AI multi-object detection and tracking, which can constantly track one of the persons and vehicles intelligently identified in the image.
· Low-profile spherical shape and 3-axis nonorthogonal mechanical stabilized structure, minimize the gyration radius and the wind resistance of the pod. The gimbal is able to spin continually around its yaw axis.
· Supports network, UART and S.BUS control and compatible with both private protocol and MAVLink protocol.
· Thanks to the Dual-IMU complementary algorithms with IMU temperature control and carrier AHRS fusion, the gimbal provides a stabilization accuracy at ±0.01°.
· Can be mounted onto multiple carriers, whether downward or upward.
· With the Dragonfly software, user can watch the image and control the pod without protocol ducking,and download photos and videos online as well.
· With the customized QGC software, all the functions of the pod can be achieved in conjunction with an open source autopilot.
· Screen supports overlaying OSD information. Image supports EXIF svaing. Live video stream and recording supports SEI saving.（The SEI functionality will be supported via subsequent firmware updates）
· 20~53 VDC wide voltage input.
[1] Reference dimension of person: 1.8x0.5m. Critical dimension under Johnson criteria is 0.75m.
[2] Reference dimension of light vehicle: 4.2x1.8m. Critical dimension under Johnson criteria is 2.3m.
[3] Reference dimension of large vehicle: 6.0x4.0m. Critical dimension under Johnson criteria is 4.9m.
[4] Measured with the pod directly wired to a computer at 1x zoom ratio. When the zoom ratio exceeds 10x, video stream delay will increase and frame rates will decrease.
