1.Built for 15-20kg MTOW professional industrial eVTOL fixed-wing UAS, with large pitch eVOTL CF 18-22" propellers, achieving high payload, high efficiency and excellent reliability, providing reliable power support for various endurance flights. Max thrust is up to 11.5kg per rotor, unit motor weighs only 270g.
| SOLUTION | ||
| VTOL Motor/KV | VTOL Prop | VTOL ESC |
| V62 210KV | Fluxer VTOL 22.1x7.4 | MAD AMPX 80A (5-14S) |
| VTOL Battery(Lipo)=/Voltage | VTOL Thrust Per Motor(kg) | The recommended takeoff weight |
| 12S(4.3V/S)/42-52V | 4kg~6kg | 20kg |
| Note.For a coaxial configuration, a total thrust loss of 25% should be considered. | ||
| SOLUTION 2 | ||
| VTOL Motor/KV | VTOL Prop | VTOL ESC |
| V62 280KV | FLUXER VTOL 18.1X7.2 | MAD AMPX 80A (5-14S) |
| VTOL Battery(Lipo)=/Voltage | VTOL Thrust Per Motor(kg) | The recommended takeoff weight |
| 12S(4.3V/S)/42-52V | 4kg~5kg | 19kg |
| Note.For a coaxial configuration, a total thrust loss of 25% should be considered. | ||
