About 3506 EEE
-
Designed for single-axis payloads of 320–720g
-
Optimized for 11–14" carbon fiber propellers
-
Delivers max thrust of 1600g per motor
-
Ultra-lightweight at only 72.3g per motor
Key Features:
✔ High thrust-to-weight ratio for agile performance
✔ Precision-balanced for smooth, efficient operation
✔ Ideal for heavy-lift drones, cinematography, and industrial applications
Perfect for:
-
Professional aerial photography
-
High-efficiency payload delivery
-
Demanding industrial UAV platforms
(Need custom KV options or bulk pricing? Contact us!)
| Motor Data | |||
|---|---|---|---|
| Motor Model | MAD 3506 EEE V3.0 | Number of pole pairs | 7 |
| Stator | High-quality Silicon steel sheets/Hight-temperature coating resistant to 180℃ | Varnished wire Degree | 150°C |
| Motor Size | D:42.5 × 23.8 mm | Magnet Degree | 150°C |
| Degree of Protection | Rain protection | Cable Length | 150 mm 18# Awg(Black) silicone |
| Centrifugal Heat Dissipation | Independent | Rotor Balance | ≤5 mg |
| Propeller Mounting Holes | D:12 M3×4 | Motor Balance | ≤10 mg |
| Shaft Diameter | IN: 4 mm | Motor Mounting Holes | D:25 M3×4 |
| Bearing | 694ZZ*2 | Disruptive test | 500 V |
